CoCo-80X: Dynamic Signal Analyzer - Handheld with Touchscreen
The CoCo-80X Dynamic Signal Analyzer features a 7-inch LCD touchscreen, 2, 4, or 8 input channels, long battery life, and optional Wi-Fi and GPS. The (ISO 11898-1&2) CAN-Bus digital input allows simultaneous measurement of an automobile’s speed, engine RPM and/or any of the hundreds of performance variables tracked by its Controlled Area Network (CAN).
CoCo-90X: 16 Channel Dynamic Signal Analyzer
The CoCo-90X operates as a dynamic signal analyzer and the software is designed for mechanical structure analysis, testing and optimization or for electrical, geophysics and a wide range of applications.
Spider-20: Wireless Dynamic Signal Analyzer
The Spider-20 is a compact yet powerful dynamic signal analyzer and data recorder with built-in Wi-Fi. It provides four 24-bit precise high-fidelity input channels, and a unique software-selectable tachometer-input/signal-source output channel. It is PC-independent and features a 6-hour battery life in full operating mode.
Spider-80Xi & Spider-80X: High Channel Count Dynamic Signal Analyzer Systems
The Spider-80X is designed for applications in three fields: dynamic data acquisition, vibration control, and machine monitoring. Scale to high channel count dynamic signal analyzer systems with channel configurations from 8 to 512 channels. The Spider-80Xi is a compact version of Spider-80X with an extremely lightweight form factor.
Spider-80X: High Channel Count Vibration Controller System
The Spider-80X is an expandable vibration control and measurement system that supports 8 to 512 input channels. Each front-end has voltage and IEPE inputs which are ideal for shock, vibration and acoustic measurement. All time data can be recorded at full speed during vibration control.
Spider-81: Premium Vibration Test Controller
The Spider-81 vibration test controller is the fourth generation of vibration control technology, integrating time-synchronized Ethernet connectivity with embedded DSP technology. Spider-81 front-ends have voltage, charge, TEDS, and IEPE inputs which are adaptable to a variety of measurements, including vibration.
Spider-81B: Basic Vibration Test Controller
The Spider-81B is a basic vibration test system. Software includes Random, Sine, Shock, and RSTD testing packages.
General Data Acquisition with Strain Gage
The Spider-80SG is a high precision, general purpose data acquisition device featuring strain gage functionality. With Crystal Instruments’ unique Ethernet based time synchronization technology, multiple Spider-80SG front-ends can be chained together to construct systems up to 512 channels. Works with the Spider-80X in DSA (dynamic signal analysis) or VCS (vibration control system) modes.
Spider-HUB Industrial Network Switch
The Spider-HUB IEEE 1588 industrial Ethernet switch supports the latest IEEE 1588v2 technology. Time stamping accuracy is guaranteed within 50 nanoseconds.
Spider-NAS Network Attached Storage Device
The Spider-NAS is a dedicated network attached storage solution designed to provide high performance data recording for front-ended Spider modules. Features a solid state hard drive of 250GB. Records data in NTFS file format.
